1. Function description of high efficiency wet mixing granulator

The high-efficiency wet mixing granulator meets the process requirements for the production of solid preparations and is made of high-quality austenitic stainless steel with an operating platform, stairs and safety guardrails. It adopts PLC control and variable frequency speed regulation. All operations can be automatically completed according to the process parameters set by the user, and all process parameters can be automatically printed. The original record is true and reliable. High-efficiency wet mixing granulator is widely used in pharmaceutical, food, dairy, chemical and other industries. It is a process equipment commonly used in production, such as the production of wet granules such as tablets, capsules and granules, with mixing, granulation, etc. A variety of functions. Meet GMP and FDA requirements.

2. Working principle of high efficiency wet mixing granulator

The high-efficiency mixing granulator is used for dry mixing and wet granulation. The material is added to the granulating pot through a vacuum feeder or a lifting feeder. The strong stirring effect of the stirring slurry is formed by the (powder) material in the container. In the axial, radial and tangential three-dimensional motion state, the pressure liquid supply system injects the adhesive through the spray gun, and the cutter rotates at a high speed to achieve the purpose of uniform mixing, and then is formed into particles by a vertical cutter; granulation After completion, the granules can be integrated with the granulator, and after wet granulation, they are dried in a fluidized bed in a closed system.

3, high efficiency wet mixing granulator features

1. Design and choose modular working platform, flexible selection of online wet granulator, with good adaptability to process and working conditions;

2. Designed to provide pressure injection adhesive injection method, atomizer metering spray to ensure uniform and stable particle composition, and rich product adaptability;

3, Cone cylinder material cylinder structure, with Z-type mixing paddle, high production efficiency, good particle flow, provide granulation end point determination function, has good process reproducibility; particles have high compression and filling;

4. Mixing paddle and granulating knife adopt composite mechanical seal and gas seal form to prevent material leakage and avoid cross-contamination;

5, Simple, reliable torque balance opening mechanism can be positioned at any angle, easy to use, safe and reduce labor intensity;

6, Touch screen control interface, the operation is intuitive and convenient, and the process parameters can be stored. The surface of the equipment is smooth, no dead ends, easy to clean, symbolic GMP and FDA requirements.
