LDG series single cone spiral vacuum dryer -- structure and characteristics

1, part of the drive, to eliminate the shaft sealing to the product may bring pollution:

Screw single cone vacuum dryer adopts part drive, relative to bottom drive, the equipment can avoid the following disadvantages:

The paddle is disassembled with special equipment for cleaning and maintenance.

Agitator shaft seals are difficult to achieve true sealing, lack of quality assurance.

2, low energy consumption cost, high mixing efficiency:

Screw single cone vacuum dryer is driven by motor, unique design, the screw driven by motor operation is used for lifting materials, no energy consumption for feeding alone.  It is particularly worth explaining that in the process of mixing and drying, the traditional mixing and drying equipment provides a belt paddle.  Its working principle is that when stirring, the moving material is like a whole, and a large amount of energy consumption is used for the circular movement of the whole material, so the drying efficiency provided by this kind of stirring is low.

Provided and LDG series series screw vacuum drying is a kind of conical spiral stirring, the impeller around the cone axis of silo in circular motion, from different parts of the whole container material can stir, as you progress through the spiral mixer, gradually will increase bunker at the bottom of the material to the top of the container, by its nature, so cycle.

This mixing mode makes the material in the container evenly mixed, eliminates the possibility of material agglomerating in the drying process, greatly improves the mixing and drying efficiency of the material.  Moreover, it has the advantages of wide range of processing capacity and low energy consumption per unit mass.

3, simple operation, convenient maintenance:

Spiral single cone vacuum drying machine structure is simple and effective, the operator is easy to understand, simple button control makes the operation process simple.  Some maintenance work can be done smoothly and quickly even without personnel, and the manholes can be easily adjusted and maintained by the moving screw without complex disassembly.  The equipment wearing parts less, bearing box and other driving units set in the bin of the part, the user in maintenance is easy to remove the whole unit, and part of the drive unit location space is also relatively abundant.
